77 42 115
Electronics Diagonal Cutter

  • Pointed head, without bevel
  • Cutting edge hardness approx. 57 HRC
  • For fine cutting work, e.g. in electronics and fine mechanics
  • Load-optimised for a more direct feel when working
  • Sturdy, zero-backlash box joint
  • Low-friction double spring for gentle and even opening
  • The polish or mirror polish together with a fine film of oil offer effective rust protection - no circuit faults caused by peeling chrome from plated tools
  • Cutters additionally laser hardened, cutter hardness at least 60 HRC
  • Narrow sleeves pulled up to the head of the pliers enable the tool to be guided securely and comfortably, also between thumb and index finger
  • Ball bearing chrome steel, oil hardened
Technical attributes
Article No.
77 42 115
EAN
4003773039761
Head
mirror polished
Handles
with multi-component grips
Weight
70 g
Dimensions
115 x 66 x 17 mm
Standard
DIN ISO 9654
REACH compliant
does not contain SVHC
RoHS compliant
not applicable
Cutting capacities medium hard wire (diameter)
Ø 0.8 mm
Cutting capacities soft wire (diameter)
Ø 0.3 – 1.3 mm
Jaw length (B)
14 mm
Jaw thickness (joint) (D)
7.5 mm
Head width (A)
11 mm

Precise cutting of fine wires and cables – even soft wires up to Ø1.3 mm

Small dimensions – large cutting capacity

Unlike diagonal cutters for use in domestic installations, this electronics diagonal cutter from Knipex is a real precision tool. With a length of 115 mm and weighing 80 g, it is extremely compact and lightweight, making it ideal for confined spaces, e.g. often found in PCBs or precision equipment. Cutting edge hardness approx. 57 HRC it cuts soft wires up to Ø1.3 mm. The short pliers head offers strong leverage. It is perfect for power delivery on the cutting edges and controlling manual force. Due to its design, the electronics diagonal cutter 77 42 115 is unsuitable for hard wire.

Zero-backlash box joint. High cut quality and durability

The Knipex 77 42 115 electronics diagonal cutter has a box joint. The inside of both pliers handles is guided. This prevents tilting. Rivets only undergo shearing stress. Result: higher-quality cutting operations, long service life. The tool is oil-hardened, while the cutting edges are induction-hardened to approx. 57 HRC.

High Knipex quality standards and corrosion protection

The high-grade workmanship of the pliers meets the requirements for electronics & precision equipment: precision, function and reliability are the key concerns. The meticulously crafted pliers are ideally suited to sensitive electronic environments. Instead of chrome plating, the Knipex 77 42 115 electronics diagonal cutter is mirror polished to prevent corrosion.

Brief overview

Comp. Diagonal cutters for fine cutting, e.g. in electronics/precision mechan.

Cutting values: soft wire Ø0.3–1.3 mm, medium-hard wire Ø0.8 mm

Box joint

Mirror polish plus fine oil film protect against rust

Forged, multistage oil-hardened with special quality tool steel

Cutting edges also induction-hardened, hardness approx. 57 HRC

Handles, multi-component grips

Length 115mm; Net weight 80 g

Electronics diagonal cutters from Knipex – for electronics & precision equipment

Knipex offers a comprehensive range of box joint electronics diagonal cutters for applications in electronics and precision equipment. They are characterised by high precision and functionality – plus the proverbial Knipex durability. Professionals who use tools a lot every day expect a quality that enables them to work easily and safely and that can withstand many years of tough service.
