77 52 115 ESDElectronics Diagonal Cutters ESD
77 52 115 ESD
Electronics Diagonal Cutters ESD
- For fine cutting work, e.g. in electronics and fine mechanics
- Electrically discharging handles - dissipative
- Sturdy, zero-backlash box joint
- Low-friction double spring for gentle and even opening
- The mirror polish in combination with a fine oil film provides rust protection - no circuit faults caused by peeling chrome from plated tools
- Cutting edges additionally induction-hardened, cutting edge hardness approx. 62 HRC
- Handles with two-colour multi-component grips black/grey
- Pointed, flat head, with small bevel
- Cutting edge hardness approx. 60 HRC
Technical attributes
Article No.
77 52 115 ESD
EAN
4003773025139
Head
mirror polished
Handles
with multi-component grips
Weight
70 g
Dimensions
115 x 66 x 17 mm
Standard
DIN ISO 9654 DIN EN 61 340-5
REACH compliant
does not contain SVHC
RoHS compliant
not applicable
Cutting capacities medium hard wire (diameter)
Ø 0.8 mm
Schneidwerte harter Draht (Durchmesser)
Ø 0.5 mm
Jaw length (B)
14 mm
Jaw thickness (joint) (D)
7 mm
Head width (A)
11 mm
ESD
yes
