95 11 225KNIPEX StepCut® XLCable shears with step cut
95 11 225
KNIPEX StepCut® XL
Cable shears with step cut
- High-leverage joint, long handles and optimised cutting edges: noticeably easier cutting than with compact cable shears
- Large cutting capacity: cuts solid copper or aluminium cables up to 35 mm², stranded cables up to 70 mm²and fine stranded cables up to 120 mm²
- Dual cutting areas: Stepped cutting edge holds small and larger cables close to the joint during the cut; the front cutting edge cuts very large cables step by step
- Easy one- or two-handed operation with minimum handle opening for large cable diameters
- Adjustable, high-leverage bolted joint provides precise and smooth cutting
- Slim head for easier accessibility
- Pinch guard prevents operators' fingers being pinched
- Not suitable for steel-reinforced cables, e.g. ACSR
- Cutting edges additionally laser-hardened, cutting edge hardness approx. 56 HRC
Technical attributes
Article No.
95 11 225
EAN
4003773088882
Shears
burnished
head
burnished
handles
plastic coated
Weight
365 g
Dimensions
229 x 46 x 15 mm
REACH compliant
does not contain SVHC
RoHS compliant
not applicable
